1. Main motor frequency conversion adjust speed
2. Small value of reduction of speed, large output torque
3. High measurement accuracy
4. The function of overvoltage, overload and short circuit
5. Seven kinds of rotation speed presetting
6. Constant temperature controlled
7. Rotation speed, count, temperature and advanced angle display
8. Built-in air supply
9. Digital display
| Rotary speed | 0~4000RPM |
| Graduated cylinder | 45ml,150ml |
| Volume of diesel fuel tank | 60L |
| Temperature auto-control | 40±2℃ |
| Filter oil precision of test bench(μ) | 4.5~5.5 |
| D.C. Supply | 12V/24V |
| Feed pressure | 0~0.4Mpa(low); 0~4Mpa(high) |
| Air pressure(Mpa) | -0.03~0.3 |
| Measuring range of flowmeter(L/m) | 10~100 |
| Flywheel inertia ((kg*m) | 0.8~0.9 |
| Center height | 125mm |
| Electricity Supply | 380V 3 phase / 220V 3 phase / 220V 1 phase |
| Output power | 7.5KW, 11KW, 15KW, 18.5KW, 22KW or as request. |
1.Measurement of each cylinder delivery at any speed.
2. Test point and interval angle of oil supply of injection pump.
3. Checking and adjust the mechanical governor.
4. Checking and adjusting the distributor pump.
5. .Experiment and adjusting of behavior of supercharging and compensatory device.
6. Measurement of oil return of distributing pump
7. Testing of the electromagnetic valve of distributor pump.(12V/24V)
8. Measurement of the internal pressure of distributor pump.
9. Checking of the advance angle of advance device.(on request)
10. Checking the sealing of injection pump body
11. Install tube of auto-sucking oil supply can check on oil supply pump(including VE pump.)
12. Forced cooling system for optional function.
